Top Pick for Home Solar Storage: 6kW Hybrid Inverter, Grid-Tie & Off-Grid, Outdoor Direct Install, Smart Load Management
|
MODEL |
AEP-6KP1-D5 |
|
Battery Input |
|
|
Max. Discharging Current
|
135A
|
|
Charging Strategy for Lithium Battery
|
Self-adaptive Battery Management System
|
|
Battery Voltage |
48VDC |
|
Max. Charging Current |
125A
|
|
Battery Type |
Lithium/ Lead-acid |
|
Number of Battery Inputs
|
1 |
|
AC Input / Output
|
|
|
Rated AC Input/Output Active Power
|
6000W |
|
Max. AC Input/Output Apparent Power
|
6600VA
|
|
Peak Power (Off-grid)
|
>200%,15sec
|
|
Rated AC Input/Output Current
|
27.3/26.1A
|
|
Max. AC Input/Output Current
|
30/28.7A |
|
Max. Continuous AC Bypass (Grid to Load) |
40A
|
|
PV Input
|
|
|
Max. DC Input Power
|
12000W |
|
Operating Voltage Range
|
150~450V
|
|
Number of MPPT Trackers |
1+1 |
|
Max. DC Input Voltage
|
500V |
|
Start-up Voltage
|
125V
|
|
Max. Input Current
|
20/20A
|
|
Efficiency
|
|
|
Max. Efficiency |
97.6% |
|
MPPT Tracking Efficiency |
＞99%
|
|
Physical |
|
|
Protection Degree |
IP66 |
|
Dimension (W*H*D) |
338*480*205mm
|
|
Net Weight (kgs) |
13kg
|
|
Communication Interface |
GPRS / WiFi / Bluetooth / 4G / LAN (optional)
|
|
Cooling Type
|
ntelligent Forced Air Cooling
|
|
Operating Environment |
|
|
Humidity |
0% to 100% (Non-condensing)
|
|
Altitude |
≤4000m (derating above 2000m)
|
|
Operating Temperature |
-40℃~+60℃(derating above 45°C)
|
1. 6kW Hybrid Inverter: 6000W continuous power, 6000VA apparent power
2. Dual MPPT Trackers: Supports up to 12000W PV input, maximizes solar harvest
3. Wide Battery Compatibility: Works with lithium and lead-acid batteries (40-60V)
4. High Current Handling: 125A charge/discharge current for faster battery charging
5. IP66 Protection: Waterproof and dustproof for outdoor installation
6. Smart Monitoring: Optional WiFi/Bluetooth/4G communication for remote control
7. High Efficiency: Up to 97.6% efficiency with advanced cooling system
1. Peak Load Shaving: Store excess solar energy during the day and use it during evening peak hours to reduce tiered electricity bills effectively.
2. Reliable Backup Power: Automatically switches to battery power during grid outages, ensuring continuous operation of essential devices like refrigerators, lights and routers.
3. Outdoor Installation Ready: With IP66 protection, it can be installed outdoors without extra shelter, saving indoor space for homes with limited room.
1. Business Continuity Backup: Keeps cash registers, POS systems and refrigeration equipment running during power cuts, avoiding revenue loss for shops and convenience stores.
2. Cost Saving for Small Factories: Reduces peak-time grid consumption with solar storage, lowering high industrial electricity costs.
1. Independent Power for Farms & Rural Areas: Works with solar panels and batteries to build a standalone power system for irrigation, livestock farming and daily use in off-grid locations.
2. Harsh Environment Adaptability: Wide operating temperature range (-40°C ~ 60°C) and IP66 rating make it suitable for extreme weather conditions in mountainous or coastal areas.
Q1: Can I get some samples for test?
A: Yes, sample order is available for quality check and market test .
Q2: Do you accept OEM/ODM ?
A:Yes, we accept OEM/ODM with your authorization.
Q3: What is your typical delivery timeline?
A: For standard off-the-shelf products, we offer a delivery window of 5-10 business days from order confirmation. For bulk orders or customized OEM/ODM projects, delivery schedules are determined based on production capacity and customization requirements. Our sales team will provide a detailed timeline after evaluating your specific needs.
Q4: What is the standard of package?
A: We have our own design carton with five layers corrugated material; if you have any other special requirement of package, we also support customized service.
Q5: What’s your payment terms?
A: We accept T/T, L/C, WEST UNION, ALI TRADE ASSURANCE, cash.
Q6: What’s your warranty time?
A: We offer 12 months warranty service, life time technique support.
Q7: How does your factory implement quality control?
A: Quality is the cornerstone of our brand. We operate a dedicated quality assurance department that oversees every stage of production, from component sourcing to final delivery. Each product undergoes a minimum of seven rigorous quality inspection protocols before shipment, ensuring compliance with international standards and customer specifications.
Q8: How can I trust your company?
A: With over 20 years of specialized experience in inverter manufacturing, Minvon has established a robust quality management system certified to ISO 9001, ISO 14001, and ISO 45001 standards. Our products also hold CE, CCC, and RoHS certifications, ensuring compliance with international regulatory requirements. We can provide third-party assessment reports and factory audit documentation upon request to demonstrate our commitment to transparency and reliability.
Tired of complicated indoor installation and weather damage to your solar inverter? Meet the CKMINE AEP-6KP1-D5: the 6kW hybrid solar inverter built to handle outdoor life, while powering your home day and night.
🌞 Power Your Home, Rain or Shine - IP66 dustproof & waterproof rating means you can install it directly outside, no need for extra shelter. It works reliably in heavy rain, high humidity, and even extreme temperatures from -40℃ to 60℃. - Dual MPPT trackers capture more solar power, even when your panels are partially shaded, so you get every bit of energy you pay for.
⚡ Fast & Smart Energy Management - 125A ultra-fast charging current fills your batteries quickly during the day, so you have plenty of stored power for evenings or blackouts. - It automatically switches between solar, battery, grid, and generator power, prioritizing your essential loads to keep your home running.
🔋 Flexible Compatibility - Works with both lithium-ion and lead-acid batteries, giving you the freedom to choose the best option for your budget and needs. - Optional WiFi/4G module lets you monitor your system's performance from your phone, anytime, anywhere. Perfect for homeowners, small business owners, and those in off-grid areas, the AEP-6KP1-D5 combines durability, efficiency, and smart control to deliver reliable power you can count on.
