48V 51.2V 100Ah 200Ah 300Ah LiFePO4 Lithium Battery | 25.6V Wall Mount Solar Energy Storage Battery For Hybrid Solar Inverter Home Off Grid System

8000 Cycles Long Life Built-in BMS Lithium Battery, Full Protection, Support Parallel Connection, OEM Private Label, Match All Hybrid Solar Inverters

MINVON 25.6V & 51.2V LiFePO4 lithium iron phosphate battery is a wall-mounted residential energy storage battery specially matched with our D series hybrid solar inverters. This energy storage battery covers multiple capacity options from 100Ah t...

Model	25.6V -100AH	25.6V -200AH	25.6V -300AH	51.2V -100AH	51.2V -200AH	51.2V -300AH	51.2V -400AH	51.2V -460AH	51.2V -560AH	51.2V -628AH
Nominal Voltage	25.6V	25.6V	25.6V	51.2V	51.2V	51.2V	51.2V	51.2V	51.2V	51.2V
Nominal Capacity	100AH	200AH	300AH	100AH	200AH	300AH	400AH	460Ah	560AH	628AH
Nominal Energy	2.56KWH	5.12KWH	7.68KWH	5.12KWH	10.24KWH	15.36KWH	20.48KWH	23.56KWH	28.67KWH	32.15KWH
Operating Voltage Range	21.2V~28.8V	21.2V~28.8V	21.2V~28.8V	42.4V~57.6V	42.4V~57.6V	42.4V~57.6V	42.4V~57.6V	42.4V~57.6V	40.0V~58.4V	40.0V~58.4V
MAX. Charge Current	50A	100A	100A	50A	100A	100A	100A	100A	200A	200A
MAX. Discharge Current	100A	150A	200A	100A	150A	200A	200A	200A	300A	300A
Cell Configuration	8S1P	8S1P	8S1P	16S1P	16S1P	16S1P	16S2P	16S2P	16S2P	16S2P
Pack Over-Voltage Protection (V)	28.8	28.8	28.8	57.6	57.6	57.6	57.6	57.6	57.6	57.6
Pack Over-Voltage Release (V)	27.2	27.2	27.2	54.4	54.4	54.4	54.4	54.4	54.4	54.4
Pack Under-Voltage Protection (V)	21.2	21.2	21.2	42.2	42.2	42.2	42.2	42.2	42.2	42.2
Pack Under-Voltage Release (V)	24.0	24.0	24.0	48	48	48	48	48	48	48
Cell Over-Voltage Protection (V)	3.6	3.6	3.6	3.6	3.6	3.6	3.6	3.6	3.6	3.6
Cell Over-Voltage Release (V)	3.4	3.4	3.4	3.4	3.4	3.4	3.4	3.4	3.4	3.4
Cell Under-Voltage Protection (V)	2.65	2.65	2.65	2.65	2.65	2.65	2.65	2.65	2.65	2.65
Cell Under-Voltage Release (V)	2.8	2.8	2.8	2.8	2.8	2.8	2.8	2.8	2.8	2.8
Ingress Protection	IP20
Parallel Connection	Up to 16 units
Communication Port	CAN,RS485
Operating Temperature (Charge)	0~50℃
Operating Temperature (Discharge)	-10~55℃
Storage Temperature	-20~+45℃（≤1month）0~+35℃(≤1year)
Humidity	0~95%(no condensation)
Sea Level(m)	≤1500
Battery cycle times (25℃ 0.2C/0.2C 80%DOD)	≥5000 times	≥4000 times	≥8000 times	≥5000 times	≥4000 times	≥8000 times	≥4000 times	≥6000 times	≥8000 times	≥8000 times
Products Size(mm)	460X360X160	640X420X160	550X420X248	640X420X160	690X520X248	860X520X248	900X600X298	960X600X298	989X634.5X326	989X634.5X326
Package Size(mm)	520X420X220	700X480X220	610X480X310	700X480X220	780X670X440	940X670X440	980X740X440	1040X740X440	1135x695x525	1135x695x525
NW (±3kg)	24KG	44KG	56KG	44KG	89KG	121KG	145KG	168KG	206KG	207KG
GW (±3kg)	32KG	54KG	65KG	54KG	104KG	139KG	167KG	190KG	226KG	227KG

grid tie systems-0

1. Ultra Long Service Life & Safe Cell Material

✅ Automotive-grade LiFePO4 cells, cycle life up to 8000 times, service life over 10 years

✅ Non-toxic, pollution-free, eco-friendly lithium iron phosphate material, low risk of fire and explosion

✅ Stable discharge performance, no memory effect, can be charged and discharged at any time

2. Intelligent Full Protection BMS System

✅ Built-in professional BMS, automatic cell voltage & current balance

✅ All-round protection: overcharge, over-discharge, over-current, short circuit, high/low temperature protection

✅ Support unattended long-term operation, reduce after-sales maintenance cost

3. Flexible Capacity Expansion & Wide Compatibility

✅ Multiple models: 25.6V/51.2V, 100Ah~360Ah optional

✅ Max 16 units parallel connection, freely expand storage capacity for large projects

✅ Perfectly matched with all hybrid/off-grid solar inverters, plug-and-play energy storage solution

✅ Standard CAN/RS485 communication port, support remote monitoring

4. Export & Customization Support

✅ Complete CE/ISO/EMC/RoHS certificates for global customs clearance

✅ Full OEM private label service: remove factory logo, print your brand trademark

✅ Wall-mounted integrated design with wheels, easy installation and mobile transfer

✅ Stable factory stock, flexible trial order MOQ for solar importers & distributors

grid tie systems-1

grid tie systems-2

Residential Villa Solar Energy Storage System

Match with D5 series hybrid inverter, store excess solar power generated during the day for night use, provide backup power during city grid blackout, greatly cut household electricity bills.

Off-Grid Remote Rural & Farm Power Supply

Suitable for mountain villages, farms, tourist cabins without stable public grid, build independent solar power supply system together with solar panels and inverters.

Small Commercial Shop & Office Energy Storage Project

For retail stores, cafes, small workshops, store solar energy to reduce peak electricity cost, ensure stable power supply for lighting, air conditioners and office equipment.

Emergency Backup Power System

Work with solar inverter and diesel generator to form dual emergency power supply, avoid production and living losses caused by sudden power cuts.

Solar Distributor OEM Wholesale Business

Standard export energy storage battery for global solar importers in Pakistan, Turkey, Middle East, Southeast Asia, full certification and brand customization support for bulk wholesale orders.

Q1: Can I get some samples for test?

A: Yes, sample order is available for quality check and market test .

Q2: Do you accept OEM/ODM ?

A:Yes, we accept OEM/ODM with your authorization.

Q3: What is your typical delivery timeline?

A: For standard off-the-shelf products, we offer a delivery window of 5-10 business days from order confirmation. For bulk orders or customized OEM/ODM projects, delivery schedules are determined based on production capacity and customization requirements. Our sales team will provide a detailed timeline after evaluating your specific needs.

Q4: What is the standard of package?

A: We have our own design carton with five layers corrugated material; if you have any other special requirement of package, we also support customized service.

Q5: What’s your payment terms?

A: We accept T/T, L/C, WEST UNION, ALI TRADE ASSURANCE, cash.

Q6: What’s your warranty time?

A: We offer 12 months warranty service, life time technique support.

Q7: How does your factory implement quality control?

A: Quality is the cornerstone of our brand. We operate a dedicated quality assurance department that oversees every stage of production, from component sourcing to final delivery. Each product undergoes a minimum of seven rigorous quality inspection protocols before shipment, ensuring compliance with international standards and customer specifications.

Q8: How can I trust your company?

A: With over 20 years of specialized experience in inverter manufacturing, Minvon has established a robust quality management system certified to ISO 9001, ISO 14001, and ISO 45001 standards. Our products also hold CE, CCC, and RoHS certifications, ensuring compliance with international regulatory requirements. We can provide third-party assessment reports and factory audit documentation upon request to demonstrate our commitment to transparency and reliability.

Introduction

LIFEPO4 LITHIUM BATTERY 25.6V/51.2V safety and long cycle life non-toxic and eco-friendly cells cycle time up to 8000 cycles Auto-manages charge/discharge manufacture

grid tie systems-3

grid tie systems-4

grid tie systems-5

grid tie systems-6

grid tie systems-7

Adopting automotive-grade LiFePO4 cells, the battery achieves ultra-long service life with up to 8000 charge-discharge cycles, far exceeding ordinary lead-acid batteries. Equipped with an intelligent built-in BMS management system, it automatically balances the voltage and current of each cell, and provides full-range safety protection including overcharge, overdischarge, overcurrent, short circuit, high and low temperature protection, realizing unattended safe operation.

The battery supports up to 16 units in parallel expansion, which can flexibly expand energy storage capacity according to project needs. It is perfectly compatible with all mainstream hybrid/off-grid solar inverters on the market, and forms a complete off-grid/grid-tied energy storage system together with solar panels, mains electricity and generators.

The whole battery module is non-toxic and eco-friendly, with wide working temperature range, stable performance in high temperature and cold outdoor environment. We provide full OEM private label customization service, support printing your own brand logo, complete CE, ISO, EMC, ROHS certification, smooth customs clearance for Pakistan, Turkey, Middle East and Southeast Asian solar distributors.
