MINVON SOL IA-D2 Series Hybrid Solar Inverter | Reliable Home Solar & Backup Power Inverter 8-12KW for Household Energy Storage

99.9% Ultra-High Efficiency MPPT Hybrid Solar Inverter, Automatic On-Grid & Off-Grid Switch for Household Power Outage Backup, Parallel Expandable Design for Whole-Home Solar Energy Storage Expansion

MINVON SOL IA-D2 Hybrid Solar InverterIt delivers stable on-grid power for daily use and instant off-grid backup during power outages. Featuring dual MPPT controllers and 550V max PV voltage. Up to 9 inverters can run in parallel for a maximum 108kW ...

MODEL	SOL IA8000-D2	SOL IA10000-D2	SOL IA12000-D2
Input Data (DC)
Max. Recommended PV Power (for module STC)	10000W	12500W	15000W
Max. DC Voltage	550V
Start Voltage	120V
MPPT Voltage Range	60V-480V
No. of MPP Trackers	2
No. of PV Strings per MPP Tracker	1
Max. Input Current per MPP Tracker	27A
Output Data (AC)
AC Nominal Power	8000W	12000W	10000W
Max. AC Apparent Power	8000VA	12000VA	10000VA
Nominal AC Voltage	230V
AC Grid Frequency	50/60Hz
Efficiency(Line Mode)	96.50%
Output Current	34.8A	43.5A	52.2A
Battery Data (DC)
Nominal DC Voltage		48V
Max Charging And Discharging Current	190A/200A	220A/240A	250A/280A
Efficiency (Peak)	95%
Type of Battery	Lithium/Lead-acid
Backup Power (AC)
AC nominal Output Power	8000W	10000W	12000W
Nominal AC Output Voltage	230V
Nominal AC Output Frequency	50/60Hz
Switch Time	<20ms@Single <30ms@Parallel
General Data
Dimensions (W/H/D)	550465150mm
Weight	21.5kg
Noise Emission(typical)	<75dB
Self-consumption	<75W
Protection Degree	IP20
Communication	WiFi/4G

sol ia d2 series 48v hybrid solar inverter 8000w 10000w 12000w dual mppt grid tied off grid inverter 9 units parallel up to 108kw home energy storage inverter-0

Key Selling Points

1. Scalable Parallel Connection

Up to 9 units parallelable, achieving 108kW maximum power. Suitable for large villas, multi-family houses and light commercial solar storage.

2. Dual Independent MPPT Trackers

60–480V wide PV voltage, max 550V PV open-circuit voltage. Flexible panel layout and higher solar energy harvesting efficiency.

3. Dual AC Input with Built-in ATS

Supports grid and generator access with automatic switching. Eliminate extra ATS equipment to save installation cost.

4. On-Grid & Off-Grid Dual Function

On-grid peak shaving cuts power bills via surplus solar export. Ultra-fast backup power restoration within 20~30ms upon grid blackout.

5. 96% High Efficiency for 48V Lithium Battery

Perfectly tuned for 48V LiFePO4 batteries, stable bidirectional charge & discharge for household storage.

6. Dual AC Output for Load Classification

Distinguish critical & ordinary loads to avoid overload, optimizing self-consumption of solar power.

7. Mobile APP Remote Monitoring (WiFi/4G Optional)

Real-time data viewing, parameter adjustment and automatic fault alerts at your fingertips.

8. Lightweight & Space-Saving Design

IP20 indoor grade, low noise <75dB, only 21.5kg for easy wall installation, stable operation across varied temperatures.

12000 d2 high efficiency 965 hybrid inverter with smart load management-1

Suitable Application Scenarios

1. Villa Whole-Home Solar Storage

Combined with solar panels & 48V lithium batteries to achieve energy self-sufficiency. Store surplus solar power for night use and reduce monthly electricity bills.

2. Off-Grid Power for Rural Homes & Remote Cabins

Standalone operation without public grid. Cooperate with backup generators to provide stable 24-hour power supply.

3. Automatic Emergency Backup Against Power Cuts

Seamlessly switch to battery power during blackouts. Maintain continuous operation of refrigerators, lamps, water pumps and security devices.

4. Parallel Expandable System for Shops & Multi-Family Buildings

Up to 9 units parallelable to reach 108kW power output, perfect for stores, residential buildings and farm solar storage.

5. Commercial Peak Shaving Solution

Store solar energy in the daytime and discharge at peak tariff periods to lower commercial electricity costs.

Q1: Can I get some samples for test?

A: Yes, sample order is available for quality check and market test .

Q2: Do you accept OEM/ODM ?

A:Yes, we accept OEM/ODM with your authorization.

Q3: What is your typical delivery timeline?

A: For standard off-the-shelf products, we offer a delivery window of 5-10 business days from order confirmation. For bulk orders or customized OEM/ODM projects, delivery schedules are determined based on production capacity and customization requirements. Our sales team will provide a detailed timeline after evaluating your specific needs.

Q4: What is the standard of package?

A: We have our own design carton with five layers corrugated material; if you have any other special requirement of package, we also support customized service.

Q5: What’s your payment terms?

A: We accept T/T, L/C, WEST UNION, ALI TRADE ASSURANCE, cash.

Q6: What’s your warranty time?

A: We offer 12 months warranty service, life time technique support.

Q7: How does your factory implement quality control?

A: Quality is the cornerstone of our brand. We operate a dedicated quality assurance department that oversees every stage of production, from component sourcing to final delivery. Each product undergoes a minimum of seven rigorous quality inspection protocols before shipment, ensuring compliance with international standards and customer specifications.

Q8: How can I trust your company?

A: With over 20 years of specialized experience in inverter manufacturing, Minvon has established a robust quality management system certified to ISO 9001, ISO 14001, and ISO 45001 standards. Our products also hold CE, CCC, and RoHS certifications, ensuring compliance with international regulatory requirements. We can provide third-party assessment reports and factory audit documentation upon request to demonstrate our commitment to transparency and reliability.

Introduction

12kw 48v off grid on grid parallel solar energy storage inverter-0

12000 d2 high efficiency 965 hybrid inverter with smart load management-3

12000 d2 high efficiency 965 hybrid inverter with smart load management-4

12000 d2 high efficiency 965 hybrid inverter with smart load management-5

12000 d2 high efficiency 965 hybrid inverter with smart load management-6

12000 d2 high efficiency 965 hybrid inverter with smart load management-7

MINVON SOL IA-D2 Hybrid Solar Inverter

It delivers stable on-grid power for daily use and instant off-grid backup during power outages. Featuring dual MPPT controllers and 550V max PV voltage. Up to 9 inverters can run in parallel for a maximum 108kW system.

Dual AC inputs support grid power and backup generators, perfectly suited for villa home solar storage systems. Comes with CE & ISO certifications and built-in WiFi, allowing you to check real-time data remotely on your mobile APP.
